Smart Multi-mode Portable Radio

BF-SCP950

In mission-critical communication, situations are more changeable, requirements are diverse, information transmission is mixed and effective collaboration is required. Integrated with LTE and DMR, narrow and broadband, this new smart radio is designed for public safety communications with competitive Edge and abundant human-centered features. As a two-way radio, it offers instant and reliable push-to-talk calls for critical voice communications. As a ruggedized smart portable terminal, it brings all the benefits of broadband data to professional users, and offers unified communication experience, rich applications and enhanced data security.
Brochure
Inquiry
Features & Benefits
Specification
Accessories


* Multi-mode Hybrid, Flexible Communication

A multi-mode radio works in DMR conventional mode, analog conventional mode, PoC (public 3G/4G) and MC-LTE (private LTE) mode, bringing all advantages of both narrow and broad band technologies together, which could always be stay in connect.


* Intelligent Multi-application Integration Platform

Support abundant third-party customized applications like Body Worn Camera, Navigation, Workorder etc., and various sensors can be integrated to realize more functions and enrich services.


* Abundant Advanced Features

Dual SIM Dual Standby (DSDS)

WIFI

NFC

RFID

OTG

Waterproof fingerprint

Bluetooth

GPS


Rugged Screen

Visible in different lighting situations.

Super-tough, coming with IP68 rated water-resistance, a durable build with shatter-resistant display.


Dual Cameras

Front camera 8MP and rear camera 21MP, supports 4K HD video.


Dual PTT

One for DMR while another for PoC at each side, quick operation.


Perfect Audio Quality

2 microphones noise reduction and big speaker, pick up sound evenly from all directions, be heard wherever you go.


Safety Guarantee

IP68

1.5M drop test


Smart Batteries

Let you work at ease, gives you more energy, better control and longer operation life.


General
Network Mode
GSM/WCDMA/CDMA/TD-SCDMA/TDD/FDD-LTE
Band
GSM: 850/900/1800/1900; 3G: WCDMA 850/900/1900/2100 LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B20 LTE-TDD: B38/B39/B40/B41 TD_SCDMA: A/F(B34/B39) EVDO: BC0
Network type
Support Micro SIM, Micro SIM, T-Flash card
Weight
280g
Size
148.8*63.8*28(mm)
Battery
7.6V 2850mAh
Charger
USB Type-C for data copy instead of power charge
Microphone
Support dual noise reduction Mic
Configuration
Bar phone
Hardware
CPU
MTK6765 Octa-core 2.3GHz 64bit
CPU Process
16nm process
RAM+ROM (1)
4GB+64GB (standard)
RAM+ROM (2)
6GB+128GB(Optional)
TF Card
Max 512G
OS
Android 10
Display
Display Size
4.0-inch IPS
Resolution
640*1136
TP
PS/G+FF/Multi-touch, usable with gloves and wet hands
Camera
Rear Camera
21MP, support autofocus
Front Camera
8MP
Flash
1 flashlight
Environmental Performance
Vibration, Drop & Shock
MIL-STD-810G
Dust and Water Proof
SGS IP68
Working Temp.
-20℃~+60℃ / -40℃~+60℃
Connectivity
WWAN
2G:GSM 850/900/1800/1900; CDMA 3G: WCDMA 850/900/1900/2100; A/F(B34/B39) 4G: LTE-FDD: B1/B3/B5/B7/B8/B17/B20/B28(Option) LTE-TDD: B38/B39/B40/B41 Dual Micro SIM standby
BT
BT4.1
WIFI
IFI 802.11 a/b/g/n
NFC
Frequency: 13.56MH, support ISO15693, ISO1443A/B
MIC
Dual Microphones to reduce noise
FM
support
GPS
GPS/BEIDOU/GLONASS/GALILEO
DMR
/
POC Key
Support
Physical Key
PTT key, POC key, Programmable key
DMR Part
Frequency Range
VHF: 136-174MHz(Optional) UHF: 350-390MHz/ 400-480MHz/ 450-520MHz
Channels
100
Channel Spacing
12.5KHz/ 25KHz
Frequency Stability
±1.5ppm
Antenna Impedance
50Ω
Transmitter (DMR Part)
Output Power
High power: 4.0 ±0.2W Low power: 1.0 ±0.2W
4FSK Modulation
12.5KHz data only: 7K60FXD 12.5KHz data and voice: 7K60FXE
Modulation Limitation
±2.5KHz @ 12.5KHz ±5KHz @ 25KHz
Spurious Emission
-36 dBm ≤1GHz/ -30 dBm ≥1GHz
Adjacent Channel Power
≤-60dB
Frequency Response
+1/-3dB
Audio Distortion
0.03
Receiver (DMR Part)
Digital Sensitivity
5% BER: 0.25μV
Analog Sensitivity
0.22uV (12 dB SINAD)
Intermodulation
60dB
Adjacent Channel Selectivity
50dB
Spurious Suppression
ETSI/TIA603: 55dB
FM Noise
40dB @ 12.5kHz 45dB @ 25kHz
Frequency Response
+1/-3 dB
Audio Power
1.5W
Audio Distortion
≤5%
Conduction Radiation
3%(typical)
Sensor
Fingerprint
Support (optional)
G-Sensor
Support
Geomagnetic Sensor
Support
Proximity Sensor
Support
Ambient Light Sensor
Support
Gyroscope Sensor
Support
Barometric Pressure Sensor
Support (optional)
Man-down
Support(optional)
Customization
20-Pin expand
Headset Infrared camera Speaker Microphone Noise Cancellation headset RJ45 Port OTG port RS-232/RS-485
LTE Private Network
1.4G, 1.8G, 450M(B31), 600M, 700M, 230M(optional)
1D/2D Scanner
Support(optional)
Radium Lighting
Support(optional)
RFID module
Support(optional)
Infrared Remote Control
Support(optional)
